- Leica Order No. - EFERN, KUP or CHROM LLC - 182
- Production era - 1931-1936, 5,250 lenses
- Variants - Black and chrome plated versions
- Lens mount - Leica Screw-thread and M-bayonet
- Number of lenses /groups - 4 /3
- F stop range - f/4.5 > f/32
- Closest focusing distance - 1.5 m /4.82 ft
- Smallest object field -
- Diaphragm setting /type -
- Angle of view diagonal - 18 degrees
- Filter type - A36
- Accessories - Viewfinder: SYEOO Hood: IUFOO 12575
- Materials - Black lacquer and nickel or chrome plated brass
- Dimensions (length x diameter) -
- Weight - ca. 550 g /1.21 lb
- Inscription - Hektor f = 13.5 cm 1:4.5
- Forum discussion
Elmar f= 13.5 cm 1:4.5 Serial Numbers
Serial numbers compiled from Puts Pocket Pod| SN Start | SN End | Product | Year | Total |
|---|---|---|---|---|
| UNKNOWN | pre-156001 | Elmar 13.5 cm 1:4.5 | -1933 | UNKNOWN |
| 176001 | 177000 | Elmar 13.5 cm 1:4.5 | 1933 | 1000 |
| 197001 | 197500 | Elmar 13.5 cm 1:4.5 | 1934 | 500 |
| TOTAL | ASSIGNED | SERIAL NUMBERS | 1931-1936 | 1,500 |
