Rangefinder CRF 1600: Difference between revisions
From Leica Wiki (English)
Jump to navigationJump to search
mNo edit summary |
mNo edit summary |
||
| Line 4: | Line 4: | ||
*'''Delivery scope''' - Carrying cord, battery, Cordura case | *'''Delivery scope''' - Carrying cord, battery, Cordura case | ||
*'''Name and Type''' - '''Rangefinder CRF 1600''' 7 x 24 | *'''Name and Type''' - '''Rangefinder CRF 1600''' 7 x 24 | ||
:'''Rangefinder CRF 1600-B''' - the newly developed ABCTM ballistic program integrates data for the angle of declination, temperature and barometric pressure. | :'''Rangefinder CRF 1600-B''' - the newly developed ABCTM ballistic program integrates data for the angle of declination, temperature and barometric pressure. | ||
*'''Maximum range''' - 1500 m /1600 yd | |||
*'''Field of View''' - 6.6 deg - 115 m / 1000 m | *'''Field of View''' - 6.6 deg - 115 m / 1000 m | ||
*'''Weight''' - 220 g with battery | *'''Weight''' - 220 g with battery | ||
Revision as of 13:29, 17 March 2012
- Production era - 2010-2011 - Superseded by 1600-B in 2012
- Order Number - 40 528
- Delivery scope - Carrying cord, battery, Cordura case
- Name and Type - Rangefinder CRF 1600 7 x 24
- Rangefinder CRF 1600-B - the newly developed ABCTM ballistic program integrates data for the angle of declination, temperature and barometric pressure.
- Maximum range - 1500 m /1600 yd
- Field of View - 6.6 deg - 115 m / 1000 m
- Weight - 220 g with battery
- Length - 113 mm / 4.5 in
- Range - From 10 to 1200 yards with display in meters or yards
- Eye Relief - 15.0 mm
- Display & power source - 4 digit LED display with 1 x 3V / CR2 Lithium button cell
- Waterproof to Depth - 1 m / 3.2 ft
- Materials: Body and Surface - Carbon fiber-reinforced plastic & rubber eyecup
- Diopter Compensation - +/- 3.5
- On the street - $799 in 2010
