135mm f/2.8 Elmarit-M II: Difference between revisions
From Leica Wiki (English)
Jump to navigationJump to search
mNo edit summary |
mNo edit summary |
||
| Line 11: | Line 11: | ||
*'''Diaphragm setting /type''' - | *'''Diaphragm setting /type''' - | ||
*'''Angle of view''' diagonal - 18 degrees | *'''Angle of view''' diagonal - 18 degrees | ||
*'''Filter type''' - | *'''Filter type''' - E55 | ||
*'''Accessories''' - | *'''Accessories''' - | ||
*'''Materials''' - Black anodized aluminum | *'''Materials''' - Black anodized aluminum | ||
Revision as of 18:46, 18 October 2009
- Leica Order No. - 11 829 LLC - 184
- Production era - 1964-1973
- Variants -
- Lens mount - Leica M-bayonet
- Number of lenses /groups - 5 /3
- F stop range - f/2.8 > f/32
- Closest focusing distance - 1.5 m /4.92 ft
- Smallest object field -
- Diaphragm setting /type -
- Angle of view diagonal - 18 degrees
- Filter type - E55
- Accessories -
- Materials - Black anodized aluminum
- Dimensions (length x diameter) -
- Weight - 730 g /1.61 lb
- Inscription - ELMARIT-M 1:2.8/135 LEITZ CANADA 1XXXXXX
- Designer - Walter Mandler
